So I’m working on designing my own homebrew 6502-based microcomputer. I have a lot of ideas for features I’d like, but before I make too many crazy decisions I’d like to solidify my understanding of the processor I’m building the whole system around. To this end, I am grabbing my Arty-A7, a W65C02S mounted on a breadboard and a bag of jumper cables to wire them together.
I chose to use my Arty-A7 FPGA board because it has a ton of I/O pins, it can easily meet my performance requirements and because I just plain love tinkering with FPGAs.
This will take a smidge of organization to get started. I began by taking an inventory of the various pin functions on the W65C02S package.
Generally speaking, there are 16 pins for the address bus, 8 pins for the data bus, 13 control pins, 2 power pins and 1 no-connect. This means I’ll need to wire 37 IO pins + 2 power pins to my FPGA board. With that in mind I’ve decided to use a mix of the PMOD interfaces on my Arty board as well as the Arduino-shield pins next to them. Each PMOD has 8 IO pins so I’ll use 1 PMOD for the data bus and 2 for the address bus, with the control pins on adjacent shield header. I’ll pull power from one of the PMODs as well.
With my rough plan in place, I took some notes on how my 6502 pins will map to the specific pins. I planned for which PMOD pin each bit of the address and data buses will go, along with associating each control pin to a numbered shield pin. Now for the fun part!
Now that the rough planning is complete, I carefully use the wire jumpers to connect everything as planned. I wired one pin at a time roughly starting from the top of the 6502 and working down, it’s a bit of a mess but it does the job.
Now that the plumbing is in place, the real fun begins. I start by opening up Vivado and begin getting these pins mapped into a design. I’ll create a new
top.sv file to kick off the design.
`timescale 1ns / 1ps
// Arty stuff
input logic clk_100mhz,
input logic reset,
// 6502 stuff
input logic [15:0] address,
inout logic [7:0] data,
input logic vpb,
input logic phi1o,
input logic phi2o,
input logic rwb,
input logic mlb,
input logic sync,
output logic resb,
output logic sob,
output logic phi2,
output logic be,
output logic irqb,
output logic nmib,
output logic rdy
The next step is to tediously map the various pins I planned out to the pins on the pins I’ve defined in my
top module. The PMOD pins are easily found in the reference wiki for the board, but I didn’t see the IO shield pins on the primary documentation page, so I referred to the provided schematic files for that information. With all that pin mapping information, I added the pins properties into a constraints file.
At this point, everything looks to be ready for tinkering. As an initial experiment to validate that it is working, I’ll use Vivado’s VIO (Virtual Input/Output) IP block to manually probe and interact with these pins. Though, just before I generate that, I’ll add a few more lines to my
top.sv to support bi-directional use of the data bus. For the 6502, when the
rwb pin is high, the CPU is reading from the data bus, so I’ll use that as the trigger to put my
write_data on that data bus during those times.
logic [7:0] write_data;
assign data = (rwb) ? write_data : 'bZ,
sob = 1,
be = 1,
irqb = 1,
nmib = 1,
rdy = 1;
Once I am running on real hardware, I’ll be stepping through the reset logic for the 6502. So for this project
sob can all stay at
1 for now, as I won’t be using them.
Now seems like the time to start building the VIO block. I’ll add ports for the various inputs and outputs, including the register I just added for bi-directional communication on the data bus.
I’ll let Vivado synthesize the core, and I’ll add it to the
vio_0 debug_core (
.clk(clk_100mhz), // input wire clk
.probe_in0(address), // input wire [15 : 0] probe_in0
.probe_in1(data), // input wire [7 : 0] probe_in1
.probe_in2(vpb), // input wire [0 : 0] probe_in2
.probe_in3(phi1o), // input wire [0 : 0] probe_in3
.probe_in4(phi2o), // input wire [0 : 0] probe_in4
.probe_in5(rwb), // input wire [0 : 0] probe_in5
.probe_in6(mlb), // input wire [0 : 0] probe_in6
.probe_in7(sync), // input wire [0 : 0] probe_in7
.probe_out0(write_data), // output wire [7 : 0] probe_out0
.probe_out1(resb), // output wire [0 : 0] probe_out1
.probe_out2(phi2) // output wire [0 : 0] probe_out2
Now it is time for the moment of truth!
Playing with a Running CPU
With all that in place, it’s time to build everything and start playing around. After running synthesis, implementation and generating a bitfile, I can flash my new design and debug core to the Arty board and pull up the VIO interface that shows me the current state of things.
At this point a bit more knowledge on the how the 6502 operates is necessary. The
phi2 signal is the input clock for the CPU. The core of this 6502 is fully static, so this clock can be stopped at anytime and the state within the CPU preserved. This allows me to interact and step the clock manually through VIO, even though my manual input will be extremely slow for interacting with hardware.
Since the clock looks good, I’m going to perform a reset of the 6502. Near the end of the reset cycle I’m expecting the address bus to read for the reset vector, a pointer to where the CPU should begin execution after reset. For the timing requirements on getting a reset to work properly, the documentation from WDC states specifically what to do:
The Reset (RESB) input is used to initialize the microprocessor and start program execution. The RESB signal must be held low for at least two clock cycles after VDD reaches operating voltage.
When a positive edge is detected, there will be a reset sequence lasting seven clock cycles. The program counter is loaded with the reset vector from locations FFFC (low byte) and FFFD (high byte). This is the start location for program control. RESB should be held high after reset for normal operation.Western Design Center, Inc., W65C02S Datasheet
So I’ll hold reset low for at least 2 cycles, then set it back to high. I’ll continue to manually cycle the clock until I see CPU begin to fetch the
RESET vector. As that vector is read, I will manually give it the address
0xDEAD to begin execution at. Then, to keep it running I’ll give it the opcode
0xEA (NOP) so it continues to read empty instructions over the bus. It’s worth noting that the 6502 does most things in alignment to the falling edge of the
The 6502 has been reset and is running the instructions it’s reading from the FPGA! In the future I’ll extend this design to better simulate an imaginary system. That’ll be my stopping place for today, if you have any questions or feedback please leave a comment!
